MAN D2842LE410 1100hp marine engines D2842LE404 1300hp
(MAN marine engines D2842LE410 1100 hp@ 2100rpm sale for medium duty applications)
Remanufactured completely in Europe
Technical data D2842 as MAN attached.
the similar engines model (D2842 family LE 404 or LE410 model) Difference only black box EDC unit
LE404 power rating : 1300hp/2300RPM or
option settings (LE410 power rating : 1100hp/2100RPM)
Fully remanufactured.
without return old engine
in stock EU.
----------------------------------------------------
Other models available by the order:
Light Duty Operation
Engine
model1)
D 0836 LE 401
D 2866 LE 405
D 2876 LE 404
D 2876 LE 401EDC
D 2876 LE 405EDC
R6-800 CRM
D 2848 LE 401
D 2848 LE 403
V8-900 CRM
D 2840 LE 407
D 2840 LE 403EDC
V10-1100 CRM
D 2842 LE 407
D 2842 LE 404EDC
V12-1360 CRM
D 2842 LE 409
V12-1550 CRM
Medium Duty Operation
Engine
model1)
D 0836 LE 402
D 2866 LXE 40
D 2866 LE 403
D 2876 LE 402EDC
D 2848 LE 401
D 2848 LE 405
D 2840 LE
D 2840 LE 401
D 2840 LE 404EDC
D 2842 LE
D 2842 LE 401
D 2842 LE 405
D 2842 LE 413
D 2842 LE 410EDC
----------------------------------------------------
----------------------------------------------------------------------------------------------------------------------------------------------------------
Technical features D2842
Type designation LE 410EDC
Displacement l 21.93
Nominal rating 1) kW (hp) 749 (1,019)
Rated speed rpm 2,100
Torque at rated speed Nm 3,406
Maximum torque Nm 3,700
at speed rpm 1,400 –1,800
Specific fuel consumption 2) g/kWh 222
Fuel consumption 2) l / h 198
Classifiable ✓
Exhaust gas status IMO Tier 2, RCD 94/ 25/EC
--------------------------------
When putting a new or overhauled engine into operation for the first time pay attention to the "Installationinstructions for MAN marine diesel engines" without fail.
It is recommended that new or overhauled engines should not be operated at a load higher than about 75%maximum load during the first few hours of operation. Initial run-in should be at varying speeds. After thisinitial run-in, the engine should be brought up to full output gradually.
Caution:Use only approved fuels, lubricants etc. (see brochure Fuels, lubricants etc."). Otherwise the liability for defects will become null and void!
Caution:Fill the tank only when the engine is switched off. Pay attention to cleanliness. Do not spill fuel.Use only approved fuels, see brochure Fuels, lubricants etc.
Filling-in of coolantFill the cooling system of the engine with a mixture of drinkable tap water and anti-freeze agent on theethylene glycole basis or anti-corrosion agent.See Publication "Fuels, Lubricants and Coolants for MAN Diesel Engines"
---------------------------------------------------------------------------------------------------------------------------------------------
MAN
spare parts
D2842
Marine Engines
Medium Duty
ENGINE SPECIFICATIONS
Cylinder Head
Crankshaft
Seal
Gasket
Valve
Piston
Piston Ring
Liner
Bearing
Connecting Rod
Radiator
Thermostat
Spark Plug
Injector
Turbo
Fuel Injector
Ring Set
Fuel Pump
Water Pump
Oil Pump
Nozzle
Oil Pan
Flywheel
Intercooler
Aftercooler
Exhaust Manifold
Starter Motor
Alternator
Gasket Set
Connecting Rod
Valve Seal
Camshaft
Cam Follower
Cylinder Kit
man spare parts D2848
MAN
spare parts
D2848
Marine Engines
Duty Common Rail
ENGINE SPECIFICATIONS
man spare parts D2862
MAN
spare parts
D2862
Marine Engines
Medium Duty
ENGINE SPECIFICATIONS
man spare parts D2866
MAN
spare parts
D2866
Marine Engines
Heavy Duty
ENGINE SPECIFICATIONS
man spare parts D2876
MAN
spare parts
D2876
Marine Engines
Medium Duty
--------------------------------------------------------------
Also available parts for that engine:
51.01201.0467 ZYLINDERLAUFBUCHSE = 51.012010305
51.02410.6488 PLEUELLAGER
51.03101.6770 ZYLINDERKOPF
51.03203.0184 VENTILSITZRING
51.04902.0028 VENTILSCHAFTABDICHTUNG
51.05904.0127 OELWANNENDICHTUNG
51.00900.6558 ENTRUSSERSATZ
51.00900.6617 MOTORDICHTUNGSKIT
51.12503.0059 KRAFTSTOFFWECHSELFILTER
51.12503.0027 FUEL FILTER
51.05504.0087 MOTOROELFILTEREINSATZ
51.26201.7270 STARTER = 51.262017137
51.27130.0031 ANTRIEBSWELLE
51.27120.7030 DREHZAHLGEBER
8132801.6072 WINKELGETRIEBE
5027421.0033 OELDRUCKGEBER
5076034.0007 OELDRUCKGEBER
5027421.0034 TEMPERATURGEBER
5061344.1000 TEMPERATURGEBER
51.27421.0306 TEMPERATURGEBER
51.26101.7252 DREHSTROMGENERATOR
5011613.7004 Electro magnet
51.96501.0522 RUNDDICHTRING
51.96501.0496 RUNDDICHTRING
51.01222.0002 AUSGLEICHSCHEIBE
51.01601.5082 OELSPRITZDUESE
51.01114.6085 PASSLAGER
51.01110.6528 HAUPTLAGER
51.90490.0021 AUSSENSECHSRUNDSCHRAUBE
51.03201.0088 VENTILFUEHRUNG
51.03201.0102 VENTILFUEHRUNG
51.03203.0321 VENTILSITZRING
51.03901.0338 ZYLINDERKOPFDICHTUNG = 51.039010366
51.03905.0135 ZYLINDERKOPFHAUBENDICHTUNG
51.04101.0509 EINLASSVENTIL
51.04101.0501 AUSLASSVENTIL
51.05901.0146 OELKUEHLERDICHTUNG
51.05902.0050 OELKUEHLERDICHTUNG
51.05504.0087 MOTOROELFILTEREINSATZ = 51.055040069
51.06402.0084 KUEHLMITTELTHERMOSTAT
51.0251..17225 PISTON
51.0251.17225 PISTON OEM MAHLE Original 2294800
51.10101.7315 DUESENHALTERKOMBINATION
5006599.6027 WASSERPUMPENREPARATURSATZ
51.09600.7001 REGELVENTIL
51.08301.0016 LUFTFILTER
6 569 303 809 TORIC SEAL
51.06402.0084 COOLING WATER THERMOSTAT
5006599.6027 DIFFUSER
51.96501.0580 SEAL
51.96820.0286 BELT
51.01201.0467 CYLINDER LINER
51.01222.0002 SHIM
51.02400.6034 CRACK CONROD
51.04101.0509 INTAKE VALVE
51.04101.0501 EXHAUST VALVE
51.90701.0103 WASHER
51.04103.0095 SPRING SEAT
51.06500.6624 COOLANT PUMP
51.09100.7638 TURBO CHARGER
51.10101.7315 NOZLE HOLDER
51.10102.0205 INJECTION NOZZLE
51.12503.0047 STRAINER
51.96501.0544 TORIC SEAL
6 563 432 241 TORIC SEAL
51.03101.6770 CYLINDER HEAD
51.03201.0102 VALVE GUIDE NORMAL EXHAUST
51.03203.0321 VALVE SEAT RING INTAKE
51.05601.0165 OIL COOLER
51.06302.0391 COOLANT ELBOW
51.97445.0061 PROFIELD CLAMP
51.12503.0027 FUEL FILTER
51.06901.0114 GASKET
51.08101.6231 EXHAUST ELBOW LEFT
51.08101.6232 EXAUST ELBOW RIGHT
51.08901.0082 FILER SEAL
51.09500.7086 INTER COOLER
51.00904.0026 GASKET
51.06401.6005 PRESSURE REGULATOR
51.06904.0036 SEAL
51.09901.0055 GASKET FOR TURBOCHARGER
51.15901.0029 GASKET
51.15901.0026 GASKET
51.15901.0036 GASKET
6 566 310 104 SEAL
51.06102.6115 COOLANT EXPANSION TANK
51.90310.0241 DRAIN PLUG
51.08101.0852 EXHAUST MANIFOLD INNER
51.08140.0047 OIL RING
51.08140.0048 OIL RING
51.08101.6230 EXHAUST MANIFOLD
51.08201.0264 INTAKE PIPE AIR DIST.
81125030069 FILTER
